Operation via fieldbus
84
a4643-1.0 HBM: public ClipX
2 16 1 UINT8 RW Hold Min/Max flags
invert
0x4027 1
2 17 0 --- WO Clear Min/Max com-
mand
0x4028 1
2 18 1 UINT8 RW Hold Min/Max
0:normal evaluation
1:hold active
0x4029 1
2 43 1 UINT8 RW Captured value 1
filled (1: trigger has
occurred)
0x4031 1
2 44 1 UINT8 RW Captured value 2
filled (1: trigger has
occurred)
0x4031 2
2 45 1 UINT8 RW Captured value 1
status
0:valid
1: invalid
0x4032 1
2 46 1 UINT8 RW Captured value 2
status
0:valid
1: invalid
0x4032 2
2 47 4 UINT32 RW Captured value 1
trigger mask low
0x4033 1
2 48 4 UINT32 RW Captured value 2
trigger mask low
0x4033 2
2 49 4 UINT32 RW Captured value 1
trigger mask high
0x4034 1
2 50 4 UINT32 RW Captured value 2
trigger mask high
0x4034 2
DPV1
No of
bytes
Data
type
R/W Description
ClipX object
directory
Slot Index Index
Sub-
index
