Operation via fieldbus
ClipX
a4643-1.0 HBM: public 85
2 51 1 UINT8 RW Captured value 1
invert trigger
0x4035 1
2 52 1 UINT8 RW Captured value 2
invert trigger
0x4035 2
2 53 4 UINT32 RW Captured value 1
clear mask low
0x4036 1
2 54 4 UINT32 RW Captured value 2
clear mask low
0x4036 2
2 55 4 UINT32 RW Captured value 1
clear mask high
0x4037 1
2 56 4 UINT32 RW Captured value 2
clear mask high
0x4037 2
2 57 1 UINT8 RW Captured value 1
invert clear
0x4038 1
2 58 1 UINT8 RW Captured value 2
invert clear
0x4038 2
2 59 1 UINT8 RW Captured value 1
valuesource
0x4039 1
2 60 1 UINT8 RW Captured value 2
valuesource
0x4039 2
2 61 0 --- WO Command CLEAR
captured value 1
0x403a 1
2 62 0 --- WO Command CLEAR
captured value 2
0x403a 2
2 63 0 --- WO Command
TRIGGER captured
value 1
0x403b 1
DPV1
No of
bytes
Data
type
R/W Description
ClipX object
directory
Slot Index Index
Sub-
index
