ClipX device types, scope of supply
16
a4643-1.0 HBM: public ClipX
4.3 Dimensions
Fig. 2: ClipX dimensions when mounted on support rail (DIN rail 35mm to DIN
EN 60715) with 16mm depth, all measures in mm
25
35
132.6
111.7
127.7
118.6
100
To aid the design process, pre-compiled ePLAN macros (license-
free) and 3D-STEP files are available free of charge at
https://www.hbm.com/ClipX.
