HBM ClipX - Page 89

Operation via fieldbus
ClipX
a4643-1.0 HBM: public 87
2 113 4 FLOAT RW Limit switch
threshold 3
0x4604 3
2 114 4 FLOAT RW Limit switch
threshold 4
0x4604 4
2 115 4 FLOAT RW Limit switch
hysteresis 1
0x4605 1
2 116 4 FLOAT RW Limit switch
hysteresis 2
0x4605 2
2 117 4 FLOAT RW Limit switch
hysteresis 3
0x4605 3
2 118 4 FLOAT RW Limit switch
hysteresis 4
0x4605 4
2 119 1 UINT8 RW Limit switch source 1 0x4606 1
2 120 1 UINT8 RW Limit switch source 2 0x4606 2
2 121 1 UINT8 RW Limit switch source 3 0x4606 3
2 122 1 UINT8 RW Limit switch source 4 0x4606 4
2 123 1 UINT8 RW Limit switch mode 1 0x4607 1
2 124 1 UINT8 RW Limit switch mode 2 0x4607 2
2 125 1 UINT8 RW Limit switch mode 3 0x4607 3
2 126 1 UINT8 RW Limit switch mode 4 0x4607 4
2 127 4 UINT32 RW Limit switch reset
mask low 1
0x4608 1
2 128 4 UINT32 RW Limit switch reset
mask low 2
0x4608 2
2 129 4 UINT32 RW Limit switch reset
mask low 3
0x4608 3
DPV1
No of
bytes
Data
type
R/W Description
ClipX object
directory
Slot Index Index
Sub-
index
