Operation via fieldbus
ClipX
a4643-1.0 HBM: public 91
3 87 1 UINT8 RW TEDS usage
0: ignore
1: if available
2: force
0x4300 2
3 87 1 UINT8 RW TEDS search during
paraset change
0: no
1: yes
0x4300 3
3 91 2 UINT16 RO Get active param.
set
0x4270 1
3 92 2 UINT16 WO Activate a certain
param. set
0x4270 2
3 93 2 INT16 WO Command: Save
param. set to file
0x4270 3
3 94 2 UINT16 RW Boot param. set 0x4270 4
3 95 1 UINT8 RW Digital IN switch
mode
0: off
1: digital IN 0
2: digital IN 0+1
0x4270 5
3 96 0 --- WO Command: Activate
factory default
0x4270 6
3 97 4 UINT32 RO CRC of currently
used parameters
0x4270 8
3 98 0 --- WO Command: Re-
calculate CRC of
currently used
parameters
0x4270 9
DPV1
No of
bytes
Data
type
R/W Description
ClipX object
directory
Slot Index Index
Sub-
index
