Operation via fieldbus
96
a4643-1.0 HBM: public ClipX
6 14 20 STRING RO Protocol date 0x4800 14
6 20 0 STRING RO FW revision 0x4900 20
6 21 4 UINT32 RO Revision counter 0x4900 21
6 22 4 UINT32 RO HW revision 0x4900 22
6 25 32 STRING RO IM function tag 0x4900 25
6 26 22 STRING RO IM location tag 0x4900 26
6 27 16 STRING RO IM installation date 0x4900 27
6 28 54 STRING RO IM descriptor 0x4900 28
9 1 2 UINT16 RO Slot count 0x5010 1
9 2 2 UINT16 RO Free parameter
memory
0x5010 2
9 3 2 UINT16 RO Free param count 0x5010 3
9 4 2 UINT16 WO Swap with next 0x5010 4
9 11 2 UINT16 RW Function block 1 0x5001 1
9 12 2 UINT16 RW Function block 2 0x5001 2
9 13 2 UINT16 RW Function block 3 0x5001 3
9 14 2 UINT16 RW Function block 4 0x5001 4
9 15 2 UINT16 RW Function block 5 0x5001 5
9 16 2 UINT16 RW Function block 6 0x5001 6
9 41 4 FLOAT RW User signal 1 0x5003 1
9 42 4 FLOAT RW User signal 2 0x5003 2
9 43 4 FLOAT RW User signal 3 0x5003 3
DPV1
No of
bytes
Data
type
R/W Description
ClipX object
directory
Slot Index Index
Sub-
index
