the zoning configuration will be enabled. The zoning configuration can be verified after both IOMs have
been zoned.
send diagnostic: transport: Host_status=0x03 [DID_TIME_OUT]
Driver_status=0x00 [DRIVER_OK]
6. Disable zoning on IOM B using the sg_senddiag command.
a) Issue the command for IOM B that was built in the previous step.
b) Disabling a predefined zoning configuration will reset the SAS connector ports which may cause the
sg_senddiag command to return a status of DID_TIME_OUT or DID_SOFT_ERROR. Despite the error,
the zoning configuration will be enabled. The zoning configuration can be verified after both IOMs have
been zoned.
send diagnostic: transport: Host_status=0x03 [DID_TIME_OUT]
Driver_status=0x00 [DRIVER_OK]
7. Reset the both IOMs by issuing the following command:
sg_ses <dev> -p4 -c -d 02,00,00,00
8. Verify the zone groups for each of the host's has been disabled using the smp_discover_list command.
a) Issue the following command to locate the expander handles:
ls /dev/bsg
Example of the Expander Handles
0:2:0:0 9:0:1297:0 9:0:1378:0 9:0:1390:0 end_device-9:41:26
end_device-9:44:12 end_device-9:44:9
10:0:0:0 9:0:1298:0 9:0:1379:0 9:0:1391:0 end_device-9:41:27
end_device-9:44:13 expander-9:39
7:0:0:0 9:0:1299:0 9:0:1380:0 end_device-9:39:2 end_device-9:41:28
end_device-9:44:14 expander-9:40
9:0:1220:0 9:0:1300:0 9:0:1381:0 end_device-9:41:17 end_device-9:41:29
end_device-9:44:15 expander-9:41
9:0:1289:0 9:0:1301:0 9:0:1382:0 end_device-9:41:18 end_device-9:41:30
end_device-9:44:16 expander-9:42
9:0:1290:0 9:0:1302:0 9:0:1383:0 end_device-9:41:19 end_device-9:41:31
end_device-9:44:2 expander-9:43
9:0:1291:0 9:0:1303:0 9:0:1384:0 end_device-9:41:20 end_device-9:41:32
end_device-9:44:3 expander-9:44
9:0:1292:0 9:0:1304:0 9:0:1385:0 end_device-9:41:21 end_device-9:42:2
end_device-9:44:4 sas_host9
9:0:1293:0 9:0:1323:0 9:0:1386:0 end_device-9:41:22 end_device-9:44:0
end_device-9:44:5
9:0:1294:0 9:0:1375:0 9:0:1387:0 end_device-9:41:23 end_device-9:44:1
end_device-9:44:6
9:0:1295:0 9:0:1376:0 9:0:1388:0 end_device-9:41:24 end_device-9:44:10
end_device-9:44:7
9:0:1296:0 9:0:1377:0 9:0:1389:0 end_device-9:41:25 end_device-9:44:11
end_device-9:44:8
182
5 System Management
User Guide 5.2 Zoning
