DTS-60A OPERATORS MANUAL
36
Figure 3-8c – Simple Test Example
STEP 9
SELECT ENTER/BACK
STEP 10
The system ask for another test for the same oil
sample. If this is desired the user should press the
ENTER key.
ENTER
0.0
12:00 - 01/08/04 - 25 C
kV
STEP 11
The system returns to STEP 3. Using the UP and
DOWN keys the user will setup again the voltage
rate of rise. The BACK key enables/ disables the
stirrer. The ENTER key starts the second part of
the test.
60.0
PRESS ANY KEY...
kV
STIR
STEP 12
Breakdown NOT occured!
The system stop updating the voltage and the
duration. The user must press the ENTER key to
continue.
UP
DOWN
BACK
ENTER
ENTER
Continue Test?
Yes:
No:
?
ENTER
BACK
STAGE
2
STAGE
2
SELECT ENTER/BACK
The system ask for another test for the same oil
sample. If the user presses the BACK key the test
is terminated.
ENTER
Continue Test?
Yes:
No:
?
ENTER
BACK
TEST:SIMPLE TEST
TIMER:
00:01:36
VOLTAGE:
0.5 kV/s
TEST:SIMPLE TEST
TIMER:
00:00:00
VOLTAGE:
0.1 kV/s
TEST:SIMPLE TEST
TIMER:
00:02:00
VOLTAGE:
0.5 kV/s
TEST:SIMPLE TEST
TIMER:
00:02:00
VOLTAGE:
0.5 kV/s
