If the user selects the Stage then the Stage options are displayed,
Figure 4-5. The possible options are the following:
1. VOLTAGE Voltage Value + type (float)
2. DURATION Maximum Duration for Voltage V. (timer)
3. ST Stirrer Timer (timer)
4. BD WT After Breakdown Wait Timer (timer)
5. BD ST After Breakdown Stirrer Timer (yes/no)
6. BD STAGE After Breakdown goto Stage (integer)
7. BD STORE Enable/Disable Breakdown Storage (yes/no)
Figure 4-5 – Edit Program Stage
In figures 5-6a,b,c the detailed procedure for creating/editing a test is
illustrated.
VOLTAGE:
DURATION:
BD WT:
ST:
00:00:00
BD STAGE:NEXT
BD ST:
CUSTOM1 , STAGE 00
STORE BD:YES
00:00:00
00:00:00
00:00:00
0.1 kV/s
MENU
BACK
DOWN
UP
ENTER
No operation
Return to the Create/Edit Test
Move selector down
Move selector up
Enter to edit the selection
