DTS-60A OPERATORS MANUAL
66
Figure 22 – Complicated Test Program
Script File 2 – Complicated Example
prg 0 new TEST_100 2.5 0.05 mm type_I_II 00:10:00 00:00:00 07
prg 0 stage 00 001.0 kV/s 00:00:10 00:00:00 00:00:00 00:00:00 end store
prg 0 stage 01 010.0 kV 00:10:00 00:00:00 00:00:00 00:00:00 end store
prg 0 stage 02 002.0 kV/s 00:00:10 00:00:00 00:00:00 00:00:00 end store
prg 0 stage 03 030.0 kV 00:10:00 00:00:00 00:00:00 00:00:00 end store
prg 0 stage 04 002.0 kV/s 00:00:10 00:00:00 00:00:00 00:00:00 end store
prg 0 stage 05 050.0 kV 00:10:00 00:00:00 00:00:00 00:00:00 end store
prg 0 stage 06 003.0 kV/s breakdown 00:00:00 00:00:00 00:00:00 end store
prg 0
It is possible to replicate the whole test, in order to make a more
complex scenario. For example, a 4 replicated test scenario could be a Test
with 28 stages. In such a test the user should edit the After Breakdown
Stage parameter, in order for the operation to proceed with the first stage of
the next replica. It is noted that after a breakdown 10 min idle time will be
programmed and all this time the stirrer will be enabled.
Script File 3 – Replicated Complicated Example
prg 0 new TEST_101 2.5 0.05 mm type_I_II 00:10:00 00:00:00 07
prg 0 stage 00 001.0 kV/s 00:00:10 00:00:00 00:10:00 00:10:00 07 store
prg 0 stage 01 010.0 kV 00:10:00 00:00:00 00:10:00 00:10:00 07 store
prg 0 stage 02 002.0 kV/s 00:00:10 00:00:00 00:10:00 00:10:00 07 store
prg 0 stage 03 030.0 kV 00:10:00 00:00:00 00:10:00 00:10:00 07 store
prg 0 stage 04 002.0 kV/s 00:00:10 00:00:00 00:10:00 00:10:00 07 store
prg 0 stage 05 050.0 kV 00:10:00 00:00:00 00:10:00 00:10:00 07 store
prg 0 stage 06 003.0 kV/s breakdown 00:00:00 00:10:00 00:10:00 next store
prg 0 stage 07 001.0 kV/s 00:00:10 00:00:00 00:10:00 00:10:00 14 store
prg 0 stage 08 010.0 kV 00:10:00 00:00:00 00:10:00 00:10:00 14 store
prg 0 stage 09 002.0 kV/s 00:00:10 00:00:00 00:10:00 00:10:00 14 store
prg 0 stage 10 030.0 kV 00:10:00 00:00:00 00:10:00 00:10:00 14 store
prg 0 stage 11 002.0 kV/s 00:00:10 00:00:00 00:10:00 00:10:00 14 store
prg 0 stage 12 050.0 kV 00:10:00 00:00:00 00:10:00 00:10:00 14 store
prg 0 stage 13 003.0 kV/s breakdown 00:00:00 00:10:00 00:10:00 next store
prg 0 stage 14 001.0 kV/s 00:00:10 00:00:00 00:10:00 00:10:00 21 store
prg 0 stage 15 010.0 kV 00:10:00 00:00:00 00:10:00 00:10:00 21 store
prg 0 stage 16 002.0 kV/s 00:00:10 00:00:00 00:10:00 00:10:00 21 store
prg 0 stage 17 030.0 kV 00:10:00 00:00:00 00:10:00 00:10:00 21 store
prg 0 stage 18 002.0 kV/s 00:00:10 00:00:00 00:10:00 00:10:00 21 store
prg 0 stage 19 050.0 kV 00:10:00 00:00:00 00:10:00 00:10:00 21 store
prg 0 stage 20 003.0 kV/s breakdown 00:00:00 00:10:00 00:10:00 next store
prg 0 stage 21 001.0 kV/s 00:00:10 00:00:00 00:10:00 00:10:00 end store
prg 0 stage 22 010.0 kV 00:10:00 00:00:00 00:10:00 00:10:00 end store
prg 0 stage 23 002.0 kV/s 00:00:10 00:00:00 00:10:00 00:10:00 end store
prg 0 stage 24 030.0 kV 00:10:00 00:00:00 00:10:00 00:10:00 end store
prg 0 stage 25 002.0 kV/s 00:00:10 00:00:00 00:10:00 00:10:00 end store
prg 0 stage 26 050.0 kV 00:10:00 00:00:00 00:10:00 00:10:00 end store
