HIKVISION DS-2TD6267-75C4L/WY - Set Smoke Detection Parameters

Note
●
Set vertexes clockwise or anclockwise in sequence.
●
The pan angle of set area should be from 2 to 80 degrees, and lt angle should be from 1 to
45 degrees.
●
Draw four vertexes again if you want to change the shielded area.
●
When you select In Panorama Map from the drop-down list but the generaon of panorama
map failed, click
Regenerang Panorama Map... to regenerate it.
●
In the In Panorama Map mode, the pan angle and
lt angle of the set area should be within
± 60°.
5.
Check Display Shield Area to show the shield area on the live view.
6.
Click Add to save the re detecon shield, and it will be listed in the Fire Source Detecon
Shield List area; you can select a region and click Delete to delete it from the list; you can also
dene the color of the regions.
7.
Click Save.
Note
This funcon varies according to dierent camera models.
4.6 Set Smoke Detecon Parameters
To avoid the potenal smoke damage, you should congure the smoke detecon funcon for
certain areas. The detail
conguraon steps show as below.
Steps
1.
Go to Conguraon → Event → Smart Event , select Fire and Smoke Detecon.
2.
Check Enable Fire and Smoke Detecon.
3.
Refer to
Detecon Mode and Applicaon Scene for seng the smoke detecon mode.
4.
Check Display Smoke Info on Stream to display the smoke informaon on stream.
5.
Check Cancel Repeated Alarm to alarm only one
me if smoke detected in the same place.
6.
Set the Sensivity during Patrol and Vericaon Sensivity of smoke detecon. The higher the
value is, the more easily the smoke can be detected, and the false alarm rate is higher.
7.
Oponal: you can shield certain areas from being detected in smoke detecon.
1) Go to Conguraon → Event → Smart Event → Smoke Detecon Shield .
2) Check Enable Smoke
Detecon Shield .
3) Click Draw Area and drag the mouse in the live view to draw the area. Release the mouse to
nish drawing.
4) You can drag the corners of the red rectangle area to change its shape and size. Or drag the
rectangle to the
posion on your demand.
5) Click Stop Drawing.
6) Click Clear All to clear all of the seng areas.
7) Set the value of
Acve Zoom Rao on your demand, and then the shield will only appear
when the zoom rao is greater than the predened value
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
21
