Input and Measurement Specications
8. Diode test
Range Accuracy Measurement current Open circuit voltage
1.800 V ±0.5% rdg ±5 dgt 200 μA ±20% 2.0 V DC or less
Overload protection: 1000 V DC/1000 V AC or 2 × 10
7
V

Hz, whichever is
lower
(Applied for 1 minute)
Current under short circuit: 200 μA ±20%
Current under overload
Steady state: 15 mA or less
Transient state: 1.6 A or less
During the forward connection, an intermittent buzzer sounds
(Threshold: 0.15 V to 1.8 V)
When less than 0.15 V, continuous buzzer sound, red backlight turns on
9. Resistance
Range Accuracy Measurement current Open circuit voltage
600.0
Ω
±0.7% rdg ±5 dgt 200 μA ±20% 2.0 V DC or less
6.000 k
Ω
±0.7% rdg ±3 dgt 100 μA ±20% 2.0 V DC or less
60.00 k
Ω
±0.7% rdg ±3 dgt 10 μA ±20% 2.0 V DC or less
600.0 k
Ω
±0.7% rdg ±3 dgt 1 μA ±20% 2.0 V DC or less
6.000 M
Ω
±0.9% rdg ±3 dgt 100 nA ±20% 2.0 V DC or less
60.00 M
Ω
±1.5% rdg ±3 dgt 10 nA ±20% 2.0 V DC or less
Overload protection: 1000 V DC/1000 V AC or 2 × 10
7
V

Hz, whichever is
lower
(Applied for 1 minute)
Current under short circuit: 300 μA or less
Current under overload
Steady state: 15 mA or less
Transient state: 1.6 A or less
Accuracy guarantee conditions: After zero adjustment
Auto range movement threshold value: More than 6000 counts for upper
range
Less than 540 counts for lower range
