Hioki DT4261 - Page 83

77
Hold Function (HOLD)
Conceptual diagram (AC voltage)
100.0 V
Measured value
Time
(1)
Stable
range
(1) Not retained automatically (the threshold is not exceeded).
Auto holding
Example: 100.0 V
Auto holding
Example: 99.0 V
99.0 V
Threshold for
auto holding
Displayed
value
Disconnect Disconnect Disconnect
Connect Connect
Connect to the object
to be measured
Dead zone
HIOKI DT4261A961-00
