Mezzanine card numbering: CB 540A A1/B1
Figure 1-26 Mezzanine card in server blade without LOM (CB 540A A1)
Table 1-22 Location of installable components
Symbol Component Symbol Component
1 Mezzanine #1 3 Mezzanine #3
2 Mezzanine #2 4 Mezzanine #4
Figure 1-27 Mezzanine card in server blade with LOM (CB 540A B1)
Introduction
1-19
Hitachi Compute Blade 500 Series System Service Manual
