Step Symptom Possible Cause Actions / Verifications
3. If the symptom still exists, then go to
step 6.
Action 2
1. Press the power switch to power on the
suspected server blade.
Verification 2
1. If the Power LED is solid green, Error/
Fault LEDs are off and power up is
successful, then repair is completed.
2. If the symptom still exists, then go to
step 6.
4 • A server
blade is
powered
up.
• Power LED:
On.
• Error LED:
On
• Fault LED:
Off
Configuration
Error
Action 1
1. Remove the suspected server blade.
2. Inspect the connector for damage.
3. Install it into the original bay again if it
did not have damaged connector.
Verification 1
1. If the Power LED starts blink in green and
Error/Fault LEDs are off, go to Action 2.
2. If the suspected server blade has
damaged connector, then go to step 5
3. If all LEDs are still off, then go to step 6.
Action 2
1. Press the power switch to power the
suspected server blade up.
Verification 2
1. If the Power LED is solid green, then
replacing is completed.
2. If the symptom still exists, then go to
step 6.
5. • A server
blade is
powered
up.
• Power LED:
On.
• Error LED:
On
• Fault LED:
On
Hardware Error Action 1
1. Verify the Error Status through the web
console.
2. Remove the suspected server blade.
3. Replace the suspected component(s)
identified by the web console.
4. Install it into the original bay again.
Verification 1
1. If the Power LED starts blink in green and
Error/Fault LEDs are off, go to Action 2.
2. If the suspected server blade has
damaged connector, then go to step 6
3. If the symptom still exists, then go to
step 6.
Action 2
Troubleshooting
11-9
