GR2K-GA-1002 3-1
Rev. 6.03
Chapter 3
Component Details
3.1 Cabinet (Chassis)
Table3-1showstheinstalleddimensionsandthemassofeachGR2000cabinet
model. The mass assumes the case when each cabinet model is installed with full
options (maximum configuration). This table also refers to the minimum service
clearance for maintaining or installing each cabinet model, differentiated by the type
of installation (e.g., desktop, floor, and rack-mount). Figure 3-1 illustrates the
minimum service clearance for desktop or floor installation, while Figure 3-2
illustrates the same for rack-mount installation (common among cabinet models).
See Section Subsection 2.2 for the external images of these cabinet models.
Table 3-1 Installed Dimensions, Masses, and Minimum Service Clearances
Cabinet Model Approx. Dimensions mm Approx.
Mass kg
Type of Installation and Minimum Service
Clearance
Height Width Depth
GR2000-2S 90 440 480 15 • Desktop: See Figure 3-1.
• Rack-mount: See Figure 3-2.
GR2000-4S 180 440 480 25 • Desktop: See Figure 3-1.
• Rack-mount: See Figure 3-2.
GR2000-6H 360 440 480 50 • Desktop: See Figure 3-1.
• Rack-mount: See Figure 3-2.
GR2000-10H 630 440 600 110 • Floor: See Figure 3-1.
• Rack-mount: See Figure 3-2.
GR2000-20H 890 440 600 150 • Floor: See Figure 3-1.
• Rack-mount: See Figure 3-2.
GR2000-4 130 440 600 25 • Desktop: See Figure 3-1.
• Rack-mount: See Figure 3-2.
GR2000-10 750 430 600 85 • Floor: See Figure 3-1.
• Rack-mount: See Figure 3-2.
GR2000-20 1450 440 600 190 • Floor: See Figure 3-1.
• Rack-mount: See Figure 3-2.
