Figure 3-95 Construction of duel shield type coaxial cable

3.10.2.6 Multimode Optical Fiber Cable for OC-3c/STM-1 (POS) MMF

Multimode connection with the OC-3c/STM-1 (POS) MMF interface requires an

optical fiber cable with the specifications shown in Figure 3-96. One or more cab

ofthesametypeisrecommendedtobepreparedforspare.

nner conductor

Shield 1

Jacket

Shield 2

Insulator

For connection to box

1-core FC/SC/ST connector x 2 (box side)
