Hitachi GR2000 Series - POW-M100 and POW-L200; Pow-S100

Figure 3-63 illustrates the power unit of the POW-S100. The dimensions are
approximate (in mm), and the drawing is not to scale.
Figure 3-63 Power Unit of POW-S100
3.6.10 POW-M100 and POW-L200
Figure 3-64 illustrates the power unit of the POW-M100 and the POW-L200. The
dimensions are approximate (in mm), and the drawing is not to scale.
0
190
230
