is NIF has four ports for
connection with 8-pin modular connectors of RJ-45 in compliance with IS8877.
Table 3-36 shows the connector specifications.
Figure 3-34 NWMX1-4 Front Panel View
Switch and LED indication
Table 3-35 WMX-1-4 switch and function of LED indications
Name LED: Color Status Content
STATUS LED: Green/
Yellow/ Red
Shows the operating
condition of NIF.
Green: Operable operation
Yellow: Blocking and the board replaceable state.
NWMX-4
LINE 0
LINE 1LINE 2LINE 3
LINE ERR
ACT
T/R
STATUS
ISDN/HSD 1.5Mbps (JAPAN)
