3.5 Network Interface Module (NIF)
Various types of NIF models are provided as listed in Table 3-15. Each NIF model
comprises one NIF board. Description of each NIF board follows.
Table 3-15 NIF Models
Category Physical Interface NIF Name Board Size Remarks
LAN 10BASE-T,
100BASE-TX
NE100-8T Half size, 30mm wide 100m
NE100-8TA Half size, 30mm wide VRRP, MPLS support, 100m
100BASE-FX NE100-4F Half size, 30mm wide MMF, 2km
NE100-4FS** Half size, 30mm wide SMF middle distance, 15km
NE100-4FS4** Half size, 30mm wide SMF long distance, 40km
1000BASE-SX NE1G-1S Full size, 30mm wide 550m
NE1G-1SA Full size, 30mm wide VRRP, MPLS support, 550m
NE1G-1SB Full size VRRP, MPLS, VLAN,
Bandwidth control support,
550m
1000BASE-LX NE1G-1L Full size, 30mm wide 550m
NE1G-1LA Full size, 30mm wide VRRP, MPLS support, 550m
NE1G-1LB Full size VRRP, MPLS, VLAN,
Bandwidth control support,
550m
NE1G-4C Full size, 30mm wide GBIC Support, VRRP, MPLS,
VLAN, Bandwidth control
support
1000BASE-LH NE1G-1LHA** Full size, 30mm wide 40km
NE1G-1LHA8** Full size, 30mm wide 80 km support
NE1G-1LHBA** Full size, 30mm wide 100km
WAN V.24/V.35/X.21 NWVX-4 Half size, 30mm wide 16m
Highspeed digital NWJB-8* Half size, 30mm wide Basic, Japan only, 16m
NWJ1-4U* Half size, 30mm wide Primary, Japan only, 200m
NWJ1-8U* Half size, 30mm wide Primary, Japan only, 200m
NWMX1-4* Half size, 30mm wide Basic+primary, Japan only,
200m
NWT1-4 Half size, 30mm wide Primary, North America, 1800m
NWE1-4 Half size, 30mm wide Primary, Europe, Asia, 1800m
NWE1-8 Halfsize, 30mm wide MPLS support
NWJ2-1U* Half size, 30mm wide Secondary, Japan only, 16m
NWT3-2U Half size, 30mm wide Tertiary, North America, 137m
NWE3-1C Half size, 30mm wide 34 MB Multiplexed, 137m
NWE3-2U Half size, 30mm wide Tertiary, Europe, 137m
OC-3c/STM-1 (POS) NWOC3C-2M Half size, 30mm wide MMF, 2km
NWOC3C-2S Half size, 30mm wide SMF, 15km
NWOC3C-2MD Half size, 30mm wide MPLS support, 2km
NWOC3C-8M Full size, 30mm wide 2km
NWOC3C-2SD Half size, 30mm wide MPLS support, 15km
NWOC3C-8S Full size, 30mm wide 15km
OC-12c/STM-4 (POS) NWOC12C-1S Full size, 30mm wide 15km
NWOC12-4M Full size, 30mm wide 500m
NWOC12-1SD Full size, 30mm wide MPLS supoort, 15km
NWOC12-4S Full size, 30mm wide 15 km
