The communication speed varies depending on the port connected to the console.
When connecting the console to CONSOLE (RS232C), the communication speed can
be selected from the above table. The standard speed is 9600bps.
The communication speed when the console is connected to AUX is 9600bps.
The cable to connect the console with this devices is the RS-232C cross cable.
The connector on this device side is the D-SUB CON female of 9 pins.
Table 6-2 Console specifications
Item Specifications
Communication parameter 8 bits and 1 stop bit, without parity.
Communication speed 19.2 kbps
9600 bps
4800 bps
2100 bps
1200 bps
