TheappearanceoftheV.24interfacecableisasshowninFigure3-71.Figure3-72
shows the cable specifications.
When connecting to a TA or modem on the V.24 interface, an HN-F9355-71H cabl
(5m), its option for 1m to 16m (request for price quotation basis), or an
HN-F9355-71F cable (3m) is applicable. The HN-F9355-71F is required for
connection to a 28.8kbps modem.
When using the own router as a DCE and connecting to a DTE-attached cable on th
V.24 interface, an HN-F9355-75H cable (5m) is applicable. This direct connection
allowsthelinespeedof19.2kbpsorless,andthemaximumcablelengthof16m
between the DCE and the DTE.
Line speed range (XR bit/S) Cable length limitation Coordinating cable
9.6 < X < 19.2 16m or shorter. HN-F9355-71H (5m)
Cables other than 5m are coordinated
individually.
19.2 < X <
28.8 3m or shorter. HN-F9355-71F (3m)
(Note 1) It is 2.4 < x < 19.2 in NWVX-8.
To Next Page
