Hitachi GR2000 Series - Nwj2-1 U

TheNWJ2-1UphysicallyappearsasFigure3-38.ThisNIFhasoneportfor
connection with a pair of BNC connectors (receive and transmit). Table 3-47 shows
the connector specifications.
Figure 3-38 NWJ2-1U Front Panel View
Switch and LED indication
Table 3-45 NW2J-1U switch and function of LED indications
Name LED: Color Status Content
STATUS LED: Green/
Yellow/ Red
Shows the operating
condition of NIF.
Green: Operable operation
Yellow: Blocking and the board replaceable state.
NWJ2-1U
L
INE 0
T
R
LINE ERR
ACT
T/R
RAI
LOS
AIS
STATUS
HSD 6.3Mbps UNCHANNELIZED (JAPAN)
