2.5 Connections
2.5.1 Interface Cables and Connectors
Most interface cables are customer responsibilities. Prepare appropriate interface
cables with connectors, according to Table 2-10. Further explanation follows.
Table 2-10 Specifications of Interface Cables and Connectors
Physical Interface NIF Name Cable Specifications/Notes Length (m) Connector
Min. Max.
10BASE-T NE100-8T,
NE100-8TA,
NE100-8TB
UTP category 3/4/5, 4, 8-core, 2-pair
straight
-- 100 RJ-45
100BASE-TX NE100-8T,
NE100-8TA,
NE100-8TB
UTP category 5, 8-core, 4-pair straight -- 100 RJ-45
100BASE-FX NE100-4F Multimode optical fiber of 62.5/125
µm
core/clad, 1300 nm wavelength
22kSC2-core
NE100-4FS** Single-mode optical fiber of 10/125
µm
core/clad, 1300 nm wavelength
215kSC2-core
NE100-4FS4** Single-mode optical fiber of 10/125
µm
core/clad, 1300 nm wavelength
240kSC2-core
1000BASE-SX NE1G-1S,
NE1G-1SA,
NE1G-1SB
NE1G-4C
(GBIC-SX)
Multimode optical fiber of 50/125
mm
core/clad, 850 nm wavelength, 500 MHz
band
2550SC2-core
Multimode optical fiber of 62.5/125
µm
core/clad, 1300 nm wavelength, 160 MHz
band
2220SC2-core
1000BASE-LX NE1G-1L,
NE1G-1LA,
NE1G-1LB
NE1G-4C
(GBIC-SX)
Multimode optical fiber of 50/125
mm
core/clad, 850 nm wavelength, 500 MHz
band
2550SC2-core
Multimode optical fiber of 62.5/125
µm
core/clad, 1300 nm wavelength, 160 MHz
band
2220SC2-core
Single-mode optical fiber of 10/125
µm
core/clad, 1300 nm wavelength
25kSC2-core
1000BASE-LH NE1G-1LHA** Single-mode optical fiber of 10/125
µm
core/clad, 1500 nm wavelength
240kSC2core
NE1G-1LHA8** Single-mode optical fiber of 10/125
µm
core/clad, 1500 nm wavelength
280kSC2core
NE1G-1LHBA** Single-mode optical fiber of 10/125
µm
core/clad, 1500 nm wavelength
2100kSC2core
NE1G-4C
(GBIC-LH)
Single-mode optical fiber of 10/125
µm
core/clad, 1550 nm wavelength
270kSC2core
V.24 NWVX-4
NWVX-8***
Special cable, 5 m standard 1 16 Device: 50-pin
half-pitch,
Channel: 25-pin
D-sub
V.35 NWVX-4 Special cable, 5 m standard 1 16 Device: 50-pin
half-pitch,
Channel: 34-pin for
V.35
