Hitachi GR2000 Series User Manual

Product Overview
GR2K-GA-1002 2-41
Rev 6.03
Physical Interface NIF Name Cable Specifications/Notes Length (m) Connector
Min. Max.
X.21 NWVX-4 Special cable, 5 m standard 1 16 Device: 50-pin
half-pitch,
Channel: 15-pin
D-sub
Basic (I.430,
I.430-a)
NWJB-8*,
NWMX1-4**
UTP category 3/4/5, 4, 8-core,
twisted-wire, straight (Japan only)
-- 16 RJ-45
Primary (I.431,
I.431-a)
NWJ1-4U*,
NWJ1-8U*,
NWMX1-4
UTP category 3/4/5, 4, 8-core,
twisted-wire, straight (Japan only)
-- 200 Device: IS8877,
Channel: IS10173
Primary (G.703,
ANSI T1.403)
NWT1-4,
NWE1-8,
NWE1-4
UTP category 3/4/5, 4, 8-core,
twisted-wire, straight
-- 1800 RJ-48
Secondary (G.703) NWJ2-1U* Metal (coax) 3C-2V -- 16 BNC
Tertiary (G.703) NWT3-2U,
NWE3-2U,
NET3-1C,
NWE3-1C
Metal (coax) 3C-2V, 3C-2W, RG-59
(Double sealed) (Note 1) (2) * Used only
in Japan.
-- 137 BNC
OC-3c/STM-1
(POS) MMF
NWOC3C-2M,
NWOC3C-2MD,
NWOC3C-8M
Multimode optical fiber of 50/125 or 62.5/
125
mm core/clad
0.5 2 k SC 2-core/1-core
OC-3c/STM-1
(POS) SMF
NWOC3C-2S,
NWOC3C-2SD,
NWOC3C-8S
Single-mode optical fiber of 10/125
µm
core/clad
0.5 15 k SC 2-core/1-core
OC-12c/STM-4
(POS) MMF
NWOC12C-4M Single-mode optical fiber of 50/125
µmor
62.5/125
µm core/clad
0.5 500 SC 2-core/1-core
OC-12c/STM-4
(POS) MMF
NWOC12C-1S,
NWOC-12-1SD,
NWOC12-4S
Single-mode optical fiber of 10/125
µm
core/clad
0.5 15 k SC 2-core/1-core
OC-48c/STM-16
(POS)
SMF
NWOC48-1S Single-mode optical fiber of 10/125
µm
core/clad
0.5 2 k SC 2-core/1-core
NWOC48-1S4 Single-mode optical fiber of 10/125
µm
core/clad
0.5 40 k SC 2-core/1-core
NWOC48-1S8 Single-mode optical fiber of 10/125
µm
core/clad
0.5 80k SC 2-core/1-core
NWOC48-1A Single-mode optical fiber of 10/125
µm
core/clad
0.5 2k SC 2-core/1-core
NWOC48-1A4 Single-mode optical fiber of 10/125
µm
core/clad
0.5 40k SC 2-core/1-core
NWOC48-1A8 Single-mode optical fiber of 10/125
µm
core/clad
0.5 80k SC 2-core/1-core
OC-3c/STM-1
(ATM) MMF
NAOC3-1M,
NAOC3-8M**
Multimode optical fiber of 50/125 or 62.5/
125
mm core/clad
0.5 2 k SC 2-core/1-core
OC-3c/STM-1
(ATM) SMF
NAOC3-1S
NAOC3-8S**
Single-mode optical fiber of 10/125
µm
core/clad
0.5 15 k SC 2-core/1-core
Table 2-10 Specifications of Interface Cables and Connectors (continued)
