The POW-LDCH comprises one DC input unit (IN150-6U) and five DC-DC power
units (two DC03R375-Us for 3.3V dc output, two DC38001-Us for 3.3V/24V dc
output, and one DC46003-U for 3.3V/5V dc output). The POW-LDCHA comprises
one DC input unit (IN150-6U) and one DC-DC power unit (DC46003-U).
Figure 3-62 illustrates the DC input unit and (one of) the DC-DC power unit(s) of the
POW-LDCH and the POW-LDCHA. The dimensions are approximate (in mm), and the
drawing is not to scale.
Be noted that the locations for these components are fixed. See Table 3-92, and see
also Figure 2-13 and Figure 2-14 in Subsection 2.2
206.3
173.4
175
LED
SW1
