Hitachi PXR User Manual

5-3
5.1.3 Approach to the parts on the rear side of the equipment
1 Perform the operations of 1 to 3 in “5.1.2 Approach to the parts on the
front side of the equipment”.
2 Remove the fixing screws (2 pieces) of the unit door and open the unit
door.
"Caution" Take care not to cause the plumbing tube and harness to be
caught.
Unit door
Fixing screw
