Hitachi SVP F 00 Series - Physical SVP (Windows 10 Enterprise) Electrical Specifications

Item Specification
Dimensions Height: 1.7 inches (43 mm)
Width: 17.2 inches (437 mm)
Depth: 9.8 inches (249 mm)
W
eight: 10 lbs (4.5 kg)
Processor Intel N3710 Pentium processor 4C/4
threads 1.6 GHz 2M cache, 6W
Memory 2 x 4 GB DDR3 1600MHz
Storage media 1 TB 5400 RPM SATA HDD
LAN/Network interface card 1-GbE x 4 ports (on-board NIC)
x1 IPMI (BMC) port
Fans 2 x 4028 mm 13KPRM 4-pin PWM fans
Operating system Windows 10 Enterprise
Maximum temperature Up to 40° C (104° Fahrenheit)
The SVP is supported in high-temperature
environments. Do not operate in any
location with temperatures above 40°C
(104° Fahrenheit).
Physical SVP (Windows 10 Enterprise) electrical
specifications
The following table lists the electrical specications for the physical SVP supplied by
Hitachi Vantara.
Item Specification
Rated AC voltage 100-240 V, 50-60 Hz, 4 - 2A
Power supply 200 W AC power supply
AC voltage 100-240 V, 50-60 Hz, 4 - 2 Amp
Power supply safety / EMC
■
USA - UL listed, FC
C
■
Canada - CUL listed
■
Germany - TUV Certied
Physical SVP (Windows 10 Enterprise) electrical specications
Chapter 3: Physical SVP (Windows 10 Enterprise) hardware description
Service Processor Technical Reference 24
