Chapter 8. Ink and Makeup Replenishment

8-12

The ink cartridge replacement (ink refilling) is now completed.

Press Complete on the guidance screen of the unit.

Pressing Complete confirms that ink refilling is complete.

[Replacement Ink cartridge] (Complete) screen

Complete
