- 20 -
HLP-C
+
Inverters
VII. Commissioning
(1) Important Checks Before the Commissioning
● If there is any wrong connected wires? Pay special attention to
the terminals: U.V.W; Make sure the power supply wires are
connected to R.S.T, not U.V.W.
● If there is any metal powder or other wires left on the base
plate of the inverter or at the terminals, which might cause
short circuit.
● If the scews are tightly locked and if the connecting parts are
loose.
● If there is any short circuit or earth fault in the output parts.
(2)Commissioning Methods
The procedure of the operator is factory set up for the control
method of HLP series. The commissioning can be carried out
through the digital operator. Generally, the commissioning can
be conducted at 5.00 Hz.
Procedures Display Indicator Lamp
POWER ON F000 FOR
、
STOP on
Press 00.00 FOR
、
STOP on
Press
05.00 FOR
、
STOP on
Press RUN F05.0 FOR
、
RUN on. The fan operates.
Press STOP F05.0 FOR
、
STOP on. The fan stops.
Note: The fan runs when the inverter is operating or the
temperature is reached within the inverter. In the process the
inverter shuts down with the operation frequency dropping to
0.00HZ, STOP indicator lamp glimmer and will be on when the
inverter stops.
