- 55 -
HLP-C
+
Inverters
C058 Multi Analog AM
Set Range
：
0~7 Factory Setting
：
0
Function: Digital frequency output terminal, In combination
with C059 it can be connected to a frequency meter with the
measuring range of 10V or below for external monitoring.
0
：
Analog Quantity Output: Displaying output frequency, 0~10V
corresponding to 0~ Max. operation frequency.
1
：
Analog Quantity Output: Displaying output current, 0~10V
corresponding to 0~2 x Rated current.
2
：
Analog Quantity Output: Displaying output DC voltage,
0~10V corresponding to 0~1000V.
3
：
Analog Quantity Output: Displaying output AC voltage,
0~10V corresponding to 0~510/255V.
4
：
Pulse Quantity Output: The corresponding relation of pulse
quantity and output frequency: 1 Pulse/Hz.
5
：
Pulse Quantity Output: The corresponding relation of pulse
quantity and output frequency: 2 Pulse/Hz.
6
：
Pulse Quantity Output: The corresponding relation of pulse
quantity and output frequency: 3 Pulse/Hz.
7
：
Pulse Quantity Output: The corresponding relation of pulse
quantity and output frequency: 6 Pulse/Hz.
C059 Analog AM Output Gain
Set Range
：
0~100% Factory Setting
：
100%
This parameter can be used to adjust the output voltage value
of the multi-output AM to suit frequency meter with different
measuring range and also used to correct a frequency meter. For
example, for an externally connected frequency meter with the
measuring range of 0~5V, a multi-function terminal can be used
to display its operation frequency. Then it can be corrected with
this parameter, Setting C059=50 will do.
*Note: When selecting a frequency meter please select one with
measuring range below 0~10V.
