- 54 -
HLP-C
+
Inverters
detects over torque.
13
：
Undervoltage alarm: The contact will act when the inverter
detects under voltage.
14
：
Single Step end: The contact will act and output a pulse
when the inverter nishes a single step in implementation of
pattern operation.
15
：
Process end: The contact will act and output a pulse when
the inverter finishes all the steps in implementation of
pattern operation (i.e. after one week).
16
：
Set Counter reach: The contact will act when the inverter
implements the external counter and the counting value is
equal to the set value (C064).
17
：
Intermediate Counter reach: The contact will act when the
inverter implements the external counter and the counting
value is more than or equal to the set value (C065).
18
：
Externally Controlled Timer 1 reach: The contact will act
when the timer reaches the set value.
19
：
Externally Controlled Timer 1 reach
20
：
4
∽
20mA disconnected. When the AI input signal is opend
the contact will act.
27
：
Drawing Reach: The contact will act when the drawing
action is nished. The contact will automatically reset when
the inverter stops.
28
：
PID Lower Limit alarm: This contact will act when the PID
feedback quantity is lower than the lower limit (C108).
29
：
PID Upper Limit alarm: This contact will act when the PID
feedback quantity is higher than the upper limit (C107).
30
：
Fan run: When the inverter is working in high temperature
or in running, this contact will act.
31
：
Electromagnetic Relay act: When the contact pulls in the
corresponding multi-function terminal will act.
32
：
Braking Resistor act: When the inverter in running and the
DC voltage reaches the braking voltage the contact will act.
