Holip hlp-c+ - Braking Resistor

- 90 -
HLP-C
+
Inverters
Inverter model
Specication
Braking torgue
10%ED
Special Motor
KW
W Q
HLPC
+
00D423B 80 200 125 0.4
HLPC
+
0D7523B 100 200 125 0.75
HLPC
+
01D523B 300 100 125 1.5
HLPC
+
02D223B 300 70 125 2.2
HLPC
+
0D7543B 80 750 125 0.75
HLPC
+
01D543B 300 400 125 1.5
HLPC
+
02D243B 300 250 125 2.2
⑶
Braking resistor
Note:
①
Please select the resistor value and working frequency given
by our company.
②
If it caused any damage to the inverter and other devices due
to the use of any braking resistor and braking model group
not supplied by our company, we will take no responsibility.
③
Be sure to consider the safety of the environment and
ignitability when installing a braking resistor. The distance
to the inverter should be 100 mm.
④
If it is necessary to change the resistor value and power value,
please contact the local distributor.
⑤
In need of a braking resistor a separate order must be placed.
Please contact the local distributor for details.
⑥
For any machine with larger inertia the capacity of the
braking resistor should be increased. Please contact the local
distributor for details.
Model Current
（
A
）
Inductance
（
mH
）
380V
class
0D7543B 2.5 8.4
01D543B 5 4.2
02D243B 7.5 3.6
