Holip hlp-c+ - C056 Multi-Output DRV; C057 Multi-Output FA, FB, FC

- 53 -
HLP-C
+
Inverters
C056 Multi-Output DRV Factory Setting
：
01
C057 Multi-Output FA, FB, FC Factory Setting
：
02
（
t1
、
t2≥2msec
）
;
⑵
When the coundting value is reached the corresponding multi-
functionoutput contact will act.
⑶
This counter is reverse counter. When the counter is reset the
setting value will be displayed and then start counting.
⑷
When the counting value is reached the displayed value is 0.
It will not count againand only start counting after it reset.
⑸
It has the function of memory. When C132=1, the counting
result can be memorized for power-off.
00
：
Invalid. When the terminal is set for no function it can
prevent false action.
01
：
Run. The contact will act when the inverter is in running or
receives the running command signals.
02
：
Fault indication. The contact will act when the inverter
detects abnormal condition.
03
：
Zero Speed: The contact will act when the inverter output
frequency is lower than its starting frequency.
04
：
DC Braking indication: The contact will act when the
inverter is in DC braking condition.
05
：
Set Frequency reach: The contact will act when the output
frequency reaches the set frequency.
06
：
Uniform Frequency 1 Reach: The contact will act when the
output frequency reaches the designated frequency (C070).
07
：
Uniform Frequency 2 reach: The contact will act when the
output frequency reaches the designated frequency (C071).
08
：
In Accel: The contact will act when the inverter is in
acceleration status.
09
：
In Decel: The contact will act when the inverter is in
deceleration status.
10
：
Inverter Overload alarm: The contact will act when the
inverter detects overload.
11
：
Motor Overload alarm: The contact will act when the
inverter detects overloadof motor.
12
：
Overtorgue detect: The contact will act when the inverter
