- 47 -
HLP-C
+
Inverters
01
：
Run: It can be combined with other terminals to combine
various control methods.
02
：
Forward rotation
03
：
Reverse rotation
04
：
Stop
05
：
For/Rev switching
06
：
Jog07
：
Jog For rotation
08
：
Jog Rev rotation
09
：
Emergency Stop: It can receive externally coming
emergency stop or other fault signals. When the terminal
is closed, the inverter will stop output and come to a stop
at free running.
10
：
Reset: This terminal can be used to reset after the fault is
removed.
12
：
Overheat of radiator or motor: This contact can be used
to detect overheat of the radiator or motor to protect the
motor and inverter.
13
：
Externally Controlled Timer 1 start: When the contact is
closed, the timer will start and begin to count time. When
the timer reaches the point the responding multi-inputs
will act.
14
：
Externally Controlled Timer 2 start
17
：
High Speed: High, inter mediate and low speed can
compose three kinds of different operation patterns.
18
：
Intermediate Speed: In the three terminals the high-end
signal has priority.
19
：
Low Speed: Low, intermediate and high speed are
determined by Frequency 2, 3, 4.
20
：
Multi-speed 1
21
：
Multi-speed 2: Multi-speed 1, 2, 3 can compose 7-Steps.
22
：
Multi-speed 3
23
：
Acel/Decel Select 1: This terminal can be used to selcect
the acel/decel time of the inverter.
24
：
Acel/Decel Select 2: 4 kinds of Acel/Decel are available
for choice.
25
：
UP f unction: When this ter mi nal switch acts the
frequency of the inverter will increase or decrease. When
the terminal switch is hold the frequency will rapidly
