2. Specifications
2.1. Performance specifications
22 Analog Input Module 2MLF-AV8A, AC8A User's Guide R200
Honeywell September 2010
Item
Specifications
2MLF-AV8A (Voltage Input Type) 2MLF-AC8A (Current Input Type)
Signed value -8000 ~ 8000
Precise value 4000 ~ 20000
0 ~ 20000
Percentile value 0 ~ 10000
• 16-bit binary value (data: 14 bits)
• You can individually set the format of digital output data for each channel either from
user program or through user-friendly GUI I/O parameter function in SoftMaster.
Maximum
resolution
Analog input range
Resolution
(1/16000)
Analog input
range
Resolution
(1/16000)
1 ~ 5V 0.250mV
4 ~ 20mA 1.0µA
0 ~ 5V 0.3125mV
0 ~ 10V 0.625mV
0 ~ 20mA 1.25µA
-10 ~ 10V 1.250mV
Accuracy
±0.2% or less (when ambient temperature is 25 ±5
o
C)
±0.3% or less (when ambient temperature is 0 ~ 55
o
C)
Maximum
conversion speed
250μs/channel
Absolute maximum
input
±15V ±30mA
Analog input
channels
8 channels/ module
Isolation method
Photo-coupler isolation between input terminal and PLC power (no isolation between
channels)
Terminal
connected
18-point terminal
I/O addresses
assigned
Fixed type: 64 points, Variable type: 16 points
