5. Configuration and Function of Internal Memory
5.1. Internal memory configuration
R200 Analog Input Module 2MLF-AV8A, AC8A User's Guide 71
September 2010 Honeywell
Setting area of Run parameters
The following table lists the details of the setting area of A/D conversion module’s Run
parameters.
Table 6 – Setting area of run parameters
Memory Address
Details R/W Remarks
Hex Dec
0
H
0 Channel enable/disable setting R/W PUT
1
H
1 Setting range of input voltage/current R/W PUT
2
H
2 Output data format setting R/W PUT
3
H
3 Filter processing enable/disable setting R/W PUT
4
H
4 CH0 filter constant
R/W
PUT
5
H
5 CH1 filter constant
6
H
6 CH2 filter constant
7
H
7 CH3 filter constant
8
H
8 CH4 filter constant
9
H
9 CH5 filter constant
A
H
10 CH6 filter constant
B
H
11 CH7 filter constant
C
H
12
Average processing enable/disable
setting
R/W
PUT
D
H
13 Average processing method setting R/W
E
H
14 CH0 average value
R/W
F
H
15 CH1 average value
10
H
16 CH2 average value
11
H
17 CH3 average value
12
H
18 CH4 average value
