5. Configuration and Function of Internal Memory
5.5. PUT/GET function block use area (parameter area)
94 Analog Input Module 2MLF-AV8A, AC8A User's Guide R200
Honeywell September 2010
Function Block Output (ANY) Type Description
GET_INT INT
Read data as much as
INT from the designated
module address
(MADDR).
GET_UINT UINT
Read data as much as
UNIT from the designated
module address
(MADDR).
GET_DINT DINT
Read data as much as
DINT from the designated
module address
(MADDR).
GET_UDINT UDINT
Read data as much as
UDINT from the
designated module
address (MADDR).
Example using PUT/GET instruction
Enable channel
1. You can enable/disable A/D conversion per channel.
2. Disable channel to reduce the conversion cycle per channel.
3. When channels not designated, all channels are set as not used.
4. Enable/disable of A/D conversion is as follows.
B15 B14 B13 B12 B11 B10 B9 B8 B7 B6 B5 B4 B3 B2 B1 B0
- - - - - - - - CH7 CH6 CH5 CH4 CH3 CH2 CH1 CH0
BIT Description
0 Stop
1 Run
