R200 Analog Input Module 2MLF-AV8A, AC8A User's Guide 129
September 2010 Honeywell
7. Troubleshooting
7.1 Error codes
Errors which occur when A/D conversion module’s RUN LED blinks are as described in
Table 7.
Table 7 – List of error codes
Error Code
(Dec)
Description
RUN LED
status
10 Module error (ASIC Reset Error).
Flickers
every
0.2s.
11 Module error (ASIC RAM or Register Error).
20 Module error (A/D Conversion Error).
30 Module error (EEPROM Error).
40#
Module error (Offset value with the range of 1 ~ 5V or 4 ~ 20mA is
set greater than or equal to Gain value.)
Flickers
every
1s.
41#
Module error (Offset value with the range of 0 ~ 5V or 0 ~ 20mA is
set greater than or equal to Gain value.)
42#
Module error (Offset value with the range of 0 ~ 10V is set greater
than or equal to Gain value.)
43#
Module error (Offset value with the range of -10 ~ 10V is set greater
than or equal to Gain value.)
50# Filter constant setting range exceeded.
60# Time average setting range exceeded.
70# Count average setting range exceeded.
80# Analog input range setting error (only for 2MLF-AC8A).
