5. Configuration and Function of Internal Memory
5.5. PUT/GET function block use area (parameter area)
90 Analog Input Module 2MLF-AV8A, AC8A User's Guide R200
Honeywell September 2010
5.5 PUT/GET function block use area (parameter area)
The following table describes operation parameter setting area of A/D conversion
module.
Global Variable Contents Read/Write Instruction
_Fab_CH_EN
Channel
Enable/Disable
Read/Write PUT
_Fab_IN_RANGE
Input current/
voltage ranges
setting
Read/Write PUT
_Fab_DATA_TYPE
Output data type
setting
Read/Write PUT
_Fab_FILT_EN
Filter processing
enable/disable
setting
Read/Write PUT
_Fab_CH0_FILT_CON
ST
CH0 filter constant
setting
Read/Write PUT
_Fab_CH1_FILT_CON
ST
CH1 filter constant
setting
_Fab_CH2_FILT_CON
ST
CH2 filter constant
setting
_Fab_CH3_FILT_CON
ST
CH3 filter constant
setting
_Fab_CH4_FILT_CON
ST
CH4 filter constant
setting
_Fab_CH5_FILT_CON
ST
CH5 filter constant
setting
_Fab_CH6_FILT_CON
ST
CH6 filter constant
setting
_Fab_CH7_FILT_CON
ST
CH7 filter constant
setting
_Fab_AVG_EN
Average processing
enable/disable
setting
Read/Write PUT
