2. Specifications
2.3. Characteristics of I/O conversion
R200 Analog Input Module 2MLF-AV8A, AC8A User's Guide 35
September 2010 Honeywell
Digital output value for current input characteristics is as specified below:
(Resolution (based on 1/16000): 1μA)
Digital output
range
Analog input current (mA)
3.808 4 8 12 16 20 20.191
Unsigned value
(-192 ~ 16191)
-192 0 4000 8000 12000 16000 16191
Signed value
(-8192 ~ 8191)
-8192 -8000 -4000 0 4000 8000 8191
Precise value
(3808 ~ 20191)
3808 4000 8000 12000 16000 20000 20191
Percentile value
(-120 ~ 10119)
-120 0 2500 5000 7500 10000 10119
