2. Specifications
2.3. Characteristics of I/O conversion
R200 Analog Input Module 2MLF-AV8A, AC8A User's Guide 37
September 2010 Honeywell
Digital output
range
Analog input current (mA)
-0.24 0 5 10 15 20 20.23
Unsigned value
(-192 ~ 16191)
-192 0 4000 8000 12000 16000 16191
Signed value
(-8192 ~ 8191)
-8192 -8000 -4000 0 4000 8000 8191
Precise value
(3808 ~ 20191)
-240 0 5000 10000 15000 20000 20239
Percentile value
(-120 ~ 10119)
-120 0 2500 5000 7500 10000 10119
CAUTION
1. If analog input value exceeds the maximum range (For example,
20mA), the digital value is fixed at maximum (For example, 16191
for unsigned) as per above table. Likewise, if analog input value
drops below minimum range (For example, 0mA), the digital value
is fixed at minimum (For example, -192 for unsigned) as per above
table.
2. Voltage and current input should not exceed ±15V and ±30mA,
respectively. Increase in temperature may lead to erratic reading.
3. You cannot modify the Offset/Gain setting for 2MLF-AV8A/AC8A
module.
