5. Configuration and Function of Internal Memory
5.5. PUT/GET function block use area (parameter area)
92 Analog Input Module 2MLF-AV8A, AC8A User's Guide R200
Honeywell September 2010
Input
REQ: execute function when 1
BASE: set base position
SLOT: set slot position
MADDR: module address
DATA: data to save module
Output
DONE: Output 1 when normal
STAT: Error information
Function
This instruction is used for reading data from designated special module.
Function Block Input (ANY) Type Description
PUT_WORD WORD
Save WRD data into the
designated module
address (MADDR).
PUT_DWORD DWORD
Save DWORD data into
the designated module
address (MADDR).
PUT_INT INT
Save INT data into the
designated module
address (MADDR).
PUT_UINT UINT
Save UNIT data into the
designated module
address (MADDR).
PUT_DINT DINT
Save DINT data into the
designated module
address (MADDR).
PUT_UDINT UDINT
Save UDINT data into the
designated module
address (MADDR).
