Galaxy Dimension Installer Manual
6-36
By default card number is empty.
To enter the required number:
1. Enter the unique 10 digit number laser etched onto the card/fob/ tag or
enter the unique RF keyfob button identifier generated by the RF RIO (refer to RF RIO programming
instructions II1-0076 for details) or
press the A and 1 keys simultaneously of the KeyProx and present the card/fob to the KeyProx reader
within five seconds. The decrypted number in the card will be self learned onto the Galaxy panel and
displayed on the KeyProx.
2. Press the ent key to save the programming and return to the previous menu level.
NOTE: A card number can be assigned to a user code that does not have a PIN allocated to it. All other
options assigned to this user are valid for the card/fob/tag button programmed.
NOTE: For access control cards, when the serial number is not printed on the card, the card number can be
learned using the add batch menu (42.3.1).
8 = MAX Function
The card/fob/tag/button can be assigned a single menu option. The user must be authorized to access the
menu option assigned to the MAX - either by the user level assigned or menu option 68 = Menu Access.
The default option is Not Used. A new option is assigned by pressing the A or B key until the required option
is displayed or by entering the option number directly and then pressing the ent to accept the selection.
9 = MAX Keypad
The menu option assigned to the MAX card can be limited to operate on a single keypad. On selecting this
option the display shows , indicating that a keypad has not been specified. To specify a keypad, press the
# key. The address of the first keypad on the system is displayed. Use the A or B key to select the required
keypad and press the ent key to accept the selection.
NOTE: The address of the keypad that is currently being used is indicated by a black square flashing over
the first digit of the keypad address.
“Card-Held” Operation
The programmed MAX function is activated when either,
• the card/fob /tag is held continuously in front of the MAX/MicroMAX/KeyProx reader for 3 seconds
or
• the programmed RF keyfob button is pressed. It should be noted that if button 1 of the RF keyfob is
programmed as a setting function, button 2 will automatically become the unset action, as long as
button 2 has been programmed for MAX operation on the RF RIO.
If using a MAX/MicroMAX or KeyProx the reader or KeyProx must be assigned a common group to the
user. The keypad specified in option 9 = MAX Keypad displays the assigned MAX function.
Assigning Dual Functions to MAX Numbers
If a card has a # assigned to the number, then any card-held function will only work in conjunction with the
PIN from the same user, provided that the PIN has a # assigned also. The Dual Focus function will work in
either order, but if the card is presented first, it will simply enable the PIN to gain access to the normal menu
(see option 42 = Codes for programming).
If a user’s card number is assigned a *, then the card becomes Dual access. This means that it will not open
42 - Codes (cont’d)
