Galaxy Dimension Installer Manual
6-91
Output Functions
The following table shows all the outputs and the zone functions and conditions that result in their activation.
53 - Program Outputs (cont’d)
Key:
S = Activates when system is set ? = Activation dependant on system programming
P = Activates when system is Part Set X = Activates during Exit Time
U = Unset E = Activates during Entry Time
A = Activated in any condition L = Switches output off if linked to destination output
- = No effect T = Activates if zone resistance is less than value for tamper s/c
O= Activates when zone is omitted or greater than value for tamper o/c
Table 6-21A. Output Activations per Zone
Output Functions Bells Strobe PA Intruder Tamper 24
Hrs
Reset Switch
DC
Set Engineer Spare Ready Security AC
Fail
Zone Function 01 02 03 04 05 06 07 08 09 10 11 12 13 14
01 Final SS–S T–X ––– –A – –
02 Exit SS–S T–– ––– –A – –
03 Intruder SS–S T–– ––– –A – –
04 24 Hours SS–S TA– ––– –A – –
05 Security SS–S T–– ––– –A A –
06 Dual SS–S T–– ––– –A – –
07 Entry SS–S T–– ––– –A – –
08 Push Set –––– T–X ––– –– – –
09 Keyswitch –––– T–XXS– –– – –
10 Secure Final SS–S T–X ––– –A U–
11 Part Final SS–S T–X ––– –A – –
12 Part Entry SS–S T–– ––– –A – –
13 PA AAA– T–– ––– –A – –
14 PA Silent ––A– T–– ––– –A – –
15 PA Delay AAA– T–– ––– –A – –
16 PA Delay Silent ––A– T–– ––– –A – –
17 Link ???? ?T?? ??? ?? ? ?
18 Spare –––– T–– ––– –– – –
19 Fire AA–– T–– ––– –– – –
20 Tamper SS–S A–– ––– –A – –
21 Bell Tamper AS–S A–– ––– –A – –
22 Beam Pair SS–S T–– ––– –A – –
23 Battery Low –––– T–– ––– –– – –
24 Line Fail –––– T–– ––– –– – –
25 AC Fail –––– T–– ––– –– – A
26 Log –––– T–– ––– –A – –
27 Remote Access –––– T–– ––– –– – –
28 Video SS–S T–– ––– –A – –
29 Video Exit SS–S T–– ––– –A – –
30 Intruder Delay SS–S T–– ––– –A – –
31 Log Delay –––– T–– ––– –– – –
32 Set Log –––– T–– ––– –– – –
33 Custom-A ???? ?T?? ??? ?? ? ?
34 Custom-B ???? ?T?? ??? ?? ? ?
35 Exitguard LLLL LTLL LLL LL L L
36 Mask SS–S T–– ––– –A – –
37 Urgent AA–A T–– ––– –A – –
38 PA Unset ––U– T–– ––– –U – –
39 Keyswitch Reset –––– T–X ––– –– – –
40 Bell fail –––– ––– ––– –– – –
41 Intr Low SS–S T–– ––– –A – –
42 Intr High SS–S T–– ––– –A – –
43 PSU Fault –––– T–– ––– –– – –
44–46 Not Used –––– ––– ––– –– – –
47 Vibration AA–A T–– ––– –A – –
48 ATM-1 AA–A T–– ––– –A – –
49 ATM-2
AA–A T–– ––– –A – –
50 ATM-3 AA–A T–– ––– –A – –
51 ATM-4 AA–A T–– ––– –A –
52 Alarm Extend AA–A T–– ––– –A – –
