Galaxy Dimension Installer Manual
6-95
Key:
S = Activates when system is set ? = Activation dependant on system programming
P = Activates when system is Part Set X = Activates during Exit Time
U = Unset E = Activates during Entry Time
A = Activated in any condition L = Switches output off if linked to destination output
- = No effect T = Activates if zone resistance is less than value for tamper s/c
O= Activates when zone is omitted or greater than value for tamper o/c
Table 6-21E. Output Activations per Zone
53 - Program Outputs (cont’d)
Output Functions Door
Prop
Door
Forced
Listen-in
Zone Function 79 80 81
01 Final –? -
02 Exit –? -
03 Intruder –? ?
04 24 Hours –? -
05 Security –? -
06 Dual –? -
07 Entry –? -
08 Push Set S? – -
09 Keyswitch –? -
10 Secure Final –? -
11 Part Final –? -
12 Part Entry –? -
13 PA –? ?
14 PA Silent –? ?
15 PA Delay –? ?
16 PA Delay Silent –? ?
17 Link ?? -
18 Spare –? -
19 Fire –? ?
20 Tamper –? -
21 Bell Tamper –? -
22 Beam Pair –? -
23 Battery Low –? -
24 Line Fail –? -
25 AC Fail –? -
26 Log –? -
27 Remote Access –? -
28 Video –? -
29 Video Exit –? -
30 Intruder Delay –? ?
31 Log Delay –? -
32 Set Log –? -
33 Custom-A ?? -
34 Custom-B ?? -
35 Exitguard LL -
36 Mask –? -
37 Urgent –? -
38 PA Unset –? ?
39 Keyswitch Reset –? -
40 Bell Fail –– -
41 Intr Low –? ?
42 Intr High –? ?
43 PSU Fault –? -
44–46 Not Used –? -
47 Vibration –? -
48 ATM-1 –? -
49 ATM-2 –? -
50 ATM-3 –? -
51 ATM-4 –? -
52 Alarm Extent –? -
