Galaxy Dimension Installer Manual
6-94
53 - Program Outputs (cont’d)
Key:
S = Activates when system is set ? = Activation dependant on system programming
P = Activates when system is Part Set X = Activates during Exit Time
U = Unset E = Activates during Entry Time
A = Activated in any condition L = Switches output off if linked to destination output
- = No effect T = Activates if zone resistance is less than value for tamper s/c
O= Activates when zone is omitted or greater than value for tamper o/c
Table 6-21D. Output Activations per Zone
Output Functions Set Late U/S
Early
Pre- Warn Autoset DR
Masked
Link A-O RF
Jam
RF
Super
Bell
Fail
Low
Volts
Lockout Vib
Test
Atm 1-4 Fault Bell Test Comms
Test
Zone Function 46 47 48 49 50 51-65 66 67 68 69 70 71 72-75 76 77 78
01 Final – – ? – – ? –––– – – – – – –
02 Exit – – ? – – ? –––– – – – – – –
03 Intruder – – ? – – ? –––– – – – – – –
04 24 Hours – – ? – – ? –––– – – – – – –
05 Security – – ? – – ? –––– – – – – – –
06 Dual – – ? – – ? –––– – – – – – –
07 Entry – – ? – – ? –––– – – – – – –
08 Push Set U? S? – – – ? –––– – – – – – –
09 Keyswitch – – ? – – ? –––– – – – – – –
10 Secure Final – – ? – – ? –––– – – – – – –
11 Part Final – – ? – – ? –––– – – – – – –
12 Part Entry – – ? – – ? –––– – – – – – –
13 PA – – ? – – ? –––– – – – – – –
14 PA Silent – – ? – – ? –––– – – – – – –
15 PA Delay – – ? – – ? –––– – – – – – –
16 PA Delay Silent – – ? – – ? –––– – – – – – –
17 Link ?? ? ?? ????–???–––
18 Spare – – ? – – ? –––– – – – – – –
19 Fire – – ? – – ? –––– – – – – – –
20 Tamper – – ? – – ? –––– – – – – – –
21 Bell Tamper – – ? – – ? –––– – – – – – –
22 Beam Pair – – ? – – ? –––– – – – – – –
23 Battery Low – – ? – – ? –––– – – – A – –
24 Line Fail – – ? – – ? –––– – – – A – –
25 AC Fail – – ? – – ? –––– – – – A – –
26 Log – – ? – – ? –––– – – – – – –
27 Remote Access – – ? – – ? –––– – – – – – –
28 Video – – ? – – ? –––– – – – – – –
29 Video Exit – – ? – – ? –––– – – – – – –
30 Intruder Delay – – ? – – ? –––– – – – – – –
31 Log Delay – – ? – – ? –––– – – – – – –
32 Set Log – – ? – – ? –––– – – – – – –
33 Custom-A ?? ? ? ? ????–???–––
34 Custom-B ?? ? ? ? ????–???–––
35 Exitguard LL L L L LLLL–LLL–––
36 Mask – – ? – – ? –––– – – – A – –
37 Urgent – – ? – – ? –––– – – – – – –
38 PA Unset – – ? – – ? –––– – – – – – –
39 Keyswitch Reset – – ? – – ? –––– – – – – – –
40 Bell Fail –– – – – –––A––––A––
41 Intr Low – – ? – – ? –––– – – – – – –
42 Intr High
– – ? – – ? –––– – – – – – –
43 PSU Fault – – ? – – ? –––– – – – A – –
44–46 Not Used – – ? – – ? –––– – – – – – –
47 Vibration – – ? – – ? –––– – A – – – –
48 ATM-1 – – ? – – ? –––– – – O – – –
49 ATM-2 – – ? – – ? –––– – – O – – –
50 ATM-3 – – ? – – ? –––– – – O – – –
51 ATM-4 – – ? – – ? –––– – – O – – –
52 Alarm Extent – – ? – – ? –––– – – – – – –
