Galaxy Dimension Installer Manual
6-146
56.6.1 Mode
The Mode option allows selection of the method of connection to the PC:
1 = Printer
This option is selected if the Galaxy is communicating with a serial printer.
2 = Direct
This mode is selected if the Galaxy panel and PC are located in close proximity to one another and can inter-
face via an RS232 cable.
3 = Modem
This mode is selected if the RS232 is communicating, via a modem and telephone line, with a remote PC.
1 = Telephone No.
The telephone number of the remote PC must be entered here.
2 = Dial Type
The type of telephone exchange (Pulse or Tone) must be assigned here.
3 = Init String
The initialisation string is an alpha-numeric string which is used to initialise the modem connected to the internal
RS232 port.
4 = Storage Mode
This mode allows the panel to emulate the behaviour of an external RS232 module which can then be attached
to another Galaxy panel to copy programming data. Refer to Appendix E for a full description of this function.
56.6.2 Format
This option allows selection of the alarm signalling format. There are two formats available for the RS232
module:
1 = SIA
Refer to the Telecom format menu (56.1.2) for programming details.
2 = Microtech
Refer to the Telecom format menu (56.1.3) for programming details.
NOTE: The SIA and Microtech formats for the RS232 module are identical in structure and programming to
the Telecom menu.
56 - Communications (cont’d)

Honeywell Galaxy Dimension series Specifications

General

Model	Galaxy Dimension series
Users	Up to 250
Partitions	Up to 8
Operating Temperature	-10°C to +55°C
Compatibility	Honeywell Galaxy accessories and peripherals
