Galaxy Dimension Installer Manual
6-145
6 = Int RS232 Port
56 - Communications (cont’d)
Figure 6-10. Internal RS232 Programming structure
The Galaxy Dimension supports an on-board RS232 serial port. This ports is:
Programmable independently from the panel.
Speed configurable from 300 to 56K bps (or highest practical speed).
Able to configure data length, parity and stop bits.
Supervised (optional via programming).
The RS232 port is configurable to support:
Connection to a PC.
Connection to a serial modem.
Connection to 3
rd
party communication modules.
Connection to serial printers.
Connection to serial wireless transmitters.
6 = Int RS232 Port
1 = Mode
1 = Printer
2 = Direct
3 = Modem
1 = Telephone No.
2 = Dial Type
1 = Tone
2 = Pulse
2 = Format
1 = SIA 0 (0-3) 1 = Trigger Events
1 = Status
2 = Groups
2 = Microtech
1 = Trigger Events
1 = Status
2 = Groups
3 = Account No.
6 digit Max.
4 = Comms Setup
3 = Init String
1 = Baud Rate
2 = Data Bits
3 = Stop Bits
4 = Parity
1 = No Parity
2 = Odd Parity
3 = Even Parity
4 = Storage Mode
