Galaxy Dimension Installer Manual
6-20
Access Log Print and Store Option
The Access Doors (MAX Log) is printed on-line and stored in the event memory.
The Access Door Log print displays in the format of the Event Log and allows information to be accessed.
The format is as follows:
HH:MM_XXXXXXXXXX_USR_NNN_UUUUUU_MYY_—_ (39 character display)
HH:MM = time in hour:minutes (5 characters). The date will be printed only at the beginning of every day,
that is midnight.
XXXXXXXXXX = access message (10 character) Valid, Invalid Card, Reject Card
USR = User (3 characters)
NNN = User number to which MAX card is assigned (3 characters)
UUUUUU = User descriptor (6 characters)
M = MAX reader address (1 character)
YY = MAX physical address-M10, M24 etc (3 characters)
- (dash) = unused character slot
__ (underscore) = this represents a space and is not printed or displayed in the access log.
For example: A valid card read at MAX
3
30 from the card held by user 020, name Albert, at 13:48 would
be:-
13:48 Valid USR 020 Albert M30 –
Access Log Information
The access log contains a reason why the door will not operate. These can be:
Not Grp Match
Reject Grp Set
Illegal Time
01:00 THU 26 APR01:00 THU 26 APR
01:00 THU 26 APR01:00 THU 26 APR
01:00 THU 26 APR
USERUSER
USERUSER
USER
001 Rejct001 Rejct
001 Rejct001 Rejct
001 Rejct
Press the # key to view the reason for rejection:
The keypad display in the access log also shows user information:
25 - Access Doors (cont’d)
The line number for MAX or prox readers is in the format, for example 0013:
00 = not required
1 = line number 1
3 = Address number 3.
10211021
10211021
1021
Grp A1Grp A1
Grp A1Grp A1
Grp A1
Reject Grp SetReject Grp Set
Reject Grp SetReject Grp Set
Reject Grp Set
Reader number
DCM Address
Line number
